更新后电源管理失效导致功耗增加

柳如嫣

设备环境：（物理机、公网、系统 0.9.30）

BUG现象：（BIOS把PCI-E 打開了ASPM, 但飛牛無法支持ASPM, 令功耗下降不了）

出现频率：（必现）

使用sudo lspci -vv 指令, 可以查看出, 以下4個元件無法打開ASPM:

00:1c.0 PCI bridge: Intel Corporation Alder Lake-S PCH PCI Express Root Port #2 (rev 11) (prog-if 00 [Normal decode])
Subsystem: Intel Corporation Alder Lake-S PCH PCI Express Root Port
LnkCap: Port #2, Speed 8GT/s, Width x1, ASPM not supported
ClockPM- Surprise- LLActRep+ BwNot+ ASPMOptComp+
LnkCtl: ASPM Disabled; RCB 64 bytes, Disabled- CommClk+

00:1c.2 PCI bridge: Intel Corporation Alder Lake-S PCH PCI Express Root Port (rev 11) (prog-if 00 [Normal decode])
Subsystem: Intel Corporation Alder Lake-S PCH PCI Express Root Port
LnkCap: Port #3, Speed 8GT/s, Width x1, ASPM not supported
ClockPM- Surprise- LLActRep+ BwNot+ ASPMOptComp+
LnkCtl: ASPM Disabled; RCB 64 bytes, Disabled- CommClk+

01:00.0 Ethernet controller: Realtek Semiconductor Co., Ltd. RTL8111/8168/8411 PCI Express Gigabit Ethernet Controller (rev 15)
Subsystem: Realtek Semiconductor Co., Ltd. RTL8111/8168/8211/8411 PCI Express Gigabit Ethernet Controller
LnkCap: Port #0, Speed 2.5GT/s, Width x1, ASPM L0s L1, Exit Latency L0s unlimited, L1 <64us
ClockPM+ Surprise- LLActRep- BwNot- ASPMOptComp+
LnkCtl: ASPM Disabled; RCB 64 bytes, Disabled- CommClk+

02:00.0 Network controller: Intel Corporation Wi-Fi 7(802.11be) AX1775*/AX1790*/BE20*/BE401/BE1750* 2x2 (rev 1a)
Subsystem: Intel Corporation Wi-Fi 7(802.11be) AX1775*/AX1790*/BE20*/BE401/BE1750* 2x2 (BE200 320MHz [Gale Peak])
LnkCap: Port #0, Speed 16GT/s, Width x1, ASPM L1, Exit Latency L1 <64us
ClockPM+ Surprise- LLActRep- BwNot- ASPMOptComp+
LnkCtl: ASPM Disabled; RCB 64 bytes, Disabled- CommClk+
ExtSynch- ClockPM+ AutWidDis- BWInt- AutBWInt-

設備:

Intel 300 (2核4線) , 內顯使用

昂達 H610SD4-ITX

DDR4 8GB x2

SATA SDD x1

Intel BE200 wifi 7

飞牛技术同学

已收到反馈，这个情况我们记录一下
